| management functions | |
| Switch-Typ | Managed |
| switch level | L2+ |
| Eigenschaft | DIN-Schiene enthalten |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 16 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Number of Gigabit Ethernet (copper) ports | 16 |
| Number of combo SPF ports | 4 |
| console port | RJ-45 |
| Number of USB 2.0 ports | 1 |
| network | |
| mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X |
| data transmission | |
| Routing/Switching Capacity | 52 Gbit/s |
| Transferrate | 77,3 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Jumbo-Frames | 10000 |
| Data packet buffer memory | 12 MB |
| safety | |
| DHCP functions | DHCP server |
| authentication | MAC-basierte Authentifizierung, Port-basierte Authentifizierung |
| authentication type | IEEE 802.1x, RADIUS |
| logs | |
| Design | |
| Product color | Schwarz |
| LED indicators | Leistung, System, USB |
| International degree of protection (IP code) | IP40 |
| Services | |
| energy | |
| energy source | Gleichstrom |
| Number of power supply units | 2 |
| Power consumption (max.) | 22 W |
| Druckanstieg-Schutzspannung | 6 kV |
| operating conditions | |
| operating temperatur | -40 - 80 °C |
| Storage temperature range | -40 - 85 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 95% |
| weight and dimensions | |
| broad | 110 mm |
| depth | 115 mm |
| height | 158 mm |
| Weight | 2,08 kg |
| scope of delivery | |
| Supplied cables | LAN (RJ-45) |
| package weight | 2,41 kg |
| Technical details | |
| Pallet length (gross) | 80 cm |
| Pallet width (gross) | 120 cm |
| certificates | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS, UKCA |
| logistic data | |
| Country of origin | China |
| Shipping box width | 580 mm |
| Shipping carton length | 310 mm |
| Shipping carton height | 255 mm |
| Goods tariff number (HS) | 851762 |
| Shipping carton weight | 15,2 kg |
| Number of products per shipping carton | 6 Stück(e) |
