management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Betriebsanleitung |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 24 |
Number of combo SPF ports | 2 |
network | |
Copper Ethernet cabling technology | 100BASE-TX, 1000BASE-T |
Virtual LAN functions | Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
Number of VLANs | 256 |
optical fiber | |
Ethernet cable cabling technology | 1000BASE-X |
data transmission | |
Routing/Switching Capacity | 52 Gbit/s |
Transferrate | 38,7 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9600 |
safety | UL 60950-1, 2nd Edition, 2014-10-14, CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10 |
DHCP functions | DHCP server, DHCP snooping, DHCP client |
Supported security algorithms | 802.1x RADIUS |
logs | |
Supported network protocols | IPv4/IPv6 |
Design | |
Product color | Schwarz |
LED indicators | Aktivität, Link, PoE, Geschwindigkeit |
Services | |
storage capacity | 128 MB |
Flash memory | 32 MB |
buffer size | 512 KB |
Mean Time Between Failures (MTBF) | 211272 h |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (standard operation) | 18,29 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 24 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 185 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
weight and dimensions | |
broad | 442 mm |
depth | 211 mm |
height | 44 mm |
Weight | 3,1 kg |
scope of delivery | |
Supplied cables | AC |
package weight | 3,5 kg |
certificates | |
certification | CE, FCC Part 15 Class A, RoHS |
logistic data | |
Country of origin | Taiwan |
Shipping box width | 482 mm |
Shipping carton length | 540 mm |
Shipping carton height | 324 mm |
Goods tariff number (HS) | 85176990 |
Shipping carton weight | 21 kg |
Number of products per shipping carton | 5 Stück(e) |
