International Protection (IP) code | IP20 |
Mounting options | Control or metering cabinet |
Product colour | Red |
Operating temperature (T-T) | -25 - 65 °C |
Depth | 23 mm |
Width | 73 mm |
Weight | 42 g |
Height | 51 mm |
Networking standards | IEEE 802.3af |
Mounting Kit | Yes |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 3 |
Maximum Input Voltage | 56 V |
Power over Ethernet (PoE) ports quantity | 3 |
Number of PoE-IN ports | 1 |
Power Over Ethernet (PoE) | Yes |
PoE-IN power consumption | 40 W |
Power consumption (typical) | 0.5 W |
Power over Ethernet (PoE) type supported | Passive PoE |
Number of PoE OUT ports | 2 |
