connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 4 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of combo SPF ports | 1 |
Quantity of SFP module slots | 1 |
network | |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Eigenschaft | Schnellstartübersicht |
data transmission | |
Routing/Switching Capacity | 12 Gbit/s |
MAC-Adressentabelle | 1024 Eintragungen |
Jumbo-Frames | 10000 |
Packet water supply system (1 Gbit / s) | 148800 pps |
Packetweiterleitungsrate (100 Mbit / s) | 148000 pps |
Packetweiterleitungsrate (10 Mbit / s) | 14880 pps |
Data packet buffer memory | 1 MB |
Design | |
Product color | Schwarz |
LED indicators | Aktivität, Link, Leistung |
energy | |
input voltage | 48 - 55 V |
Power consumption (standard operation) | 6 W |
energy conservation properties | Überlastschutz, Umgekehrte Polarität |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 4 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 126 W |
Other functions | |
operating conditions | |
operating temperatur | -40 - 75 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 40 mm |
depth | 105 mm |
height | 38 mm |
Weight | 720 g |
scope of delivery | |
packaging type | Box |
package weight | 120 g |
logistic data | |
Country of origin | Taiwan |
Goods tariff number (HS) | 85176990 |
