management functions | |
Switch-Typ | Unmanaged |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 4 |
Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
Fast Ethernet (copper) ports | 4 |
Number of fiber connectors | 1 |
Optical cable connector | SC |
network | |
mesh standard | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX |
Eigenschaft | Nachhaltigkeitskonformität |
optical fiber | |
Fibertyp | Einzelmodus |
Transmissionsentfernung (max) | 30 km |
data transmission | |
Routing/Switching Capacity | 1 Gbit/s |
MAC-Adressentabelle | 1000 Eintragungen |
Packetweiterleitungsrate (100 Mbit / s) | 148000 pps |
Packetweiterleitungsrate (10 Mbit / s) | 14880 pps |
Design | |
Product color | Schwarz |
housing material | Metall |
LED indicators | Aktivität, Link, Leistung |
International degree of protection (IP code) | IP30 |
Services | |
storage capacity | 1 MB |
Flash memory | 1 MB |
Mean Time Between Failures (MTBF) | 150000 h |
energy | |
energy source | DC/PoE |
input voltage | 0 - 56 V |
Power consumption (standard operation) | 3,76 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 126 W |
Other functions | |
operating conditions | |
operating temperatur | -40 - 75 °C |
weight and dimensions | |
broad | 114 mm |
depth | 50 mm |
height | 165 mm |
Weight | 500 g |
scope of delivery | |
packaging type | Geschenkbox |
sustainability | |
Technical details | |
Pallet length (gross) | 80 cm |
Pallet width (gross) | 120 cm |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC) |
logistic data | |
Country of origin | China |
Shipping box width | 450 mm |
Shipping carton length | 380 mm |
Shipping carton height | 320 mm |
Goods tariff number (HS) | 85176990 |
Shipping carton weight | 8 kg |
Number of products per shipping carton | 15 Stück(e) |
