management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Nachhaltigkeitskonformität |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 8 |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Virtual LAN functions | Port-based VLAN, Tagged VLAN |
Number of VLANs | 32 |
data transmission | |
Routing/Switching Capacity | 16 Gbit/s |
Transferrate | 11,904 Mpps |
MAC-Adressentabelle | 4000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 1,5 MB |
safety | |
Queue Scheduling Algorithms | Priority queuing (PQ) |
multicast capabilities | |
Design | |
Product color | Schwarz |
LED indicators | Leistung, Link, Aktivität |
International degree of protection (IP code) | IP30 |
Services | |
Flash memory | 2 MB |
noise level | 0 dB |
Mean Time Between Failures (MTBF) | 43800 h |
energy | |
energy source | DC/PoE |
DC input voltage | 44 - 57 V |
Power consumption (standard operation) | 120 W |
Druckanstieg-Schutzspannung | 4 kV |
energy conservation properties | Überspannungsschutz |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 8 |
Overall Power over Ethernet (PoE) | 112 W |
operating conditions | |
operating temperatur | -40 - 75 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
heat dissipation | 40,94 BTU/h |
weight and dimensions | |
broad | 153 mm |
depth | 114 mm |
height | 38 mm |
Weight | 550 g |
scope of delivery | |
packaging type | Box |
package weight | 780 g |
sustainability | |
Technical details | |
Anzahl der Lagen pro Palette (Luft) | 16 Stück(e) |
Pallet length (gross) | 80 cm |
Pallet width (gross) | 120 cm |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS, UKCA |
logistic data | |
Palettenhöhe (ugly) | 154,4 cm |
Country of origin | China |
Shipping box width | 480 mm |
Shipping carton length | 395 mm |
Shipping carton height | 350 mm |
Goods tariff number (HS) | 8517620090 |
Shipping carton weight | 16 kg |
Number of products per shipping carton | 20 Stück(e) |
