management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Ressourcen-CD |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 4 |
console port | RJ-45 |
network | |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
data transmission | |
Routing/Switching Capacity | 24 Gbit/s |
Transferrate | 17,856 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9216 |
Data packet buffer memory | 0,5 MB |
safety | UL,CB |
DHCP functions | DHCP server, DHCP snooping, DHCP relay, DHCP client |
logs | |
management logs | SNMP, Web, Telnet, SSH |
Supported network protocols | IPv4/IPv6 |
Design | |
Product color | Grau |
LED indicators | Alarm, Leistung, Status, System |
Services | |
storage capacity | 128 MB |
Flash memory | 32 MB |
Mean Time Between Failures (MTBF) | 476206 h |
energy | |
DC input voltage | 48 - 57 V |
Power consumption (max.) | 239,2 W |
operating conditions | |
operating temperatur | -40 - 75 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
heat dissipation | 36,03 BTU/h |
weight and dimensions | |
broad | 62 mm |
depth | 130 mm |
height | 135 mm |
Weight | 700 g |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
packaging type | Box |
package weight | 900 g |
certificates | |
certification | FCC, CE, DMS |
logistic data | |
Country of origin | Taiwan |
Shipping box width | 520 mm |
Shipping carton length | 445 mm |
Shipping carton height | 220 mm |
Goods tariff number (HS) | 85176990 |
Shipping carton weight | 2,4 kg |
Number of products per shipping carton | 10 Stück(e) |
