Housing material | Aluminium |
LED indicators | Status |
Product colour | Aluminium |
International Protection (IP) code | IP30 |
DIN rail mounting | Yes |
Wall mountable | Yes |
Rack mounting | Yes |
DC input voltage | 7 - 57 V |
Power source | DC |
Power consumption (max) | 106 W |
Power consumption (typical) | 1.8 W |
Power supply included | No |
Operating temperature (T-T) | -40 - 75 °C |
Switch type | Unmanaged |
Height | 132 mm |
Depth | 44.2 mm |
Weight | 456 g |
Width | 95.1 mm |
Networking standards | IEEE 802.3af |
Auto MDI/MDI-X | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
SFP module slots quantity | 2 |
Jumbo frames | 9216 |
MAC Address Table | 2000 entries |
Packet buffer memory | 0.128 MB |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) power per port | 30 W |
Total Power over Ethernet (PoE) budget | 240 W |
Power over Ethernet (PoE) voltage | 57 V |
Power over Ethernet (PoE) ports quantity | 8 |
