DIN rail mounting | Yes |
Product colour | Aluminium |
Stackable | No |
Housing material | Aluminium |
LED indicators | Status |
Reset button | Yes |
Rack mounting | No |
International Protection (IP) code | IP30 |
Power supply included | No |
IGMP snooping | Yes |
DHCP features | DHCP client |
Operating temperature (T-T) | -40 - 75 °C |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Web-based management | Yes |
Switch layer | L2 |
Depth | 44.2 mm |
Width | 132 mm |
Height | 122 mm |
Weight | 610 g |
Active link detection | Yes |
Link aggregation | Yes |
10G support | No |
Networking standards | IEEE 802.3af |
Full duplex | Yes |
Auto-negotiation | Yes |
Port mirroring | Yes |
VLAN support | Yes |
Gigabit Ethernet (copper) ports quantity | 8 |
Installed SFP modules quantity | 2 |
Power connector | Terminal block (3-pin) |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Jumbo frames | 10000 |
Jumbo Frames support | Yes |
Switching capacity | 20 Gbit/s |
MAC Address Table | 8000 entries |
Power over Ethernet (PoE) type supported | Active PoE |
Total Power over Ethernet (PoE) budget | 240 W |
Power over Ethernet (PoE) ports quantity | 8 |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) power per port | 30 W |
