Product colour | Black |
LED indicators | LAN |
International Protection (IP) code | IP30 |
Reset button | Yes |
Power source | DC |
Power consumption (max) | 6 W |
Power supply included | No |
Security algorithms | SNMPv3 |
DHCP features | DHCP server |
Queue scheduling algorithms | WFQ |
Operating temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 10 - 90% |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Switch layer | L2 |
Weight | 615 g |
Height | 44.2 mm |
Width | 132 mm |
Depth | 122.2 mm |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Networking standards | IEEE 802.3az |
VLAN support | Yes |
Auto MDI/MDI-X | Yes |
Port mirroring | Yes |
IP routing | Yes |
10G support | No |
Flash Memory | 16 MB |
Memory type | DDR3-SDRAM |
INTERNAL MEMORY | 128 MB |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Jumbo Frames support | Yes |
MAC Address Table | 8000 entries |
Switching capacity | 20 Gbit/s |
Jumbo frames | 10000 |
Power Over Ethernet (PoE) | No |
