Certification | CE, FCC, RoHS |
LED indicators | Activity |
Product colour | Black |
Rack mounting | No |
Wall mountable | Yes |
Housing material | Plastic |
Stackable | No |
Power source | AC |
AC input voltage | 100 - 240 V |
Power consumption (max) | 1.7 W |
Power supply included | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Depth | 52 mm |
Height | 22 mm |
Width | 82 mm |
Networking standards | IEEE 802.3ab |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 10BASE-T |
Full duplex | Yes |
MAC address auto-learning supported | Yes |
MAC address auto-aging supported | Yes |
Cable types supported | Cat3 |
Quick start guide | Yes |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Gigabit Ethernet (copper) ports quantity | 5 |
console port | RJ-45 |
Jumbo Frames support | Yes |
Switching capacity | 10 Gbit/s |
Packet buffer memory | 1 MB |
MAC Address Table | 2000 entries |
Store-and-forward | Yes |
Jumbo frames | 15 |
Forwarding rate | 7.44 Mpps |
Power Over Ethernet (PoE) | No |
