Wall mountable | Yes |
Stackable | Yes |
Rack mounting | Yes |
Housing material | Metal |
LED indicators | Link |
DC input voltage | 12 V |
Power supply included | Yes |
Power consumption (max) | 12 W |
Input current | 1 A |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power source | AC/DC |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch type | Unmanaged |
Width | 235 mm |
Height | 27 mm |
Depth | 103 mm |
Auto-negotiation | Yes |
Cable types supported | Cat5 |
Full duplex | Yes |
10G support | No |
MAC address auto-learning supported | Yes |
Networking standards | IEEE 802.3 |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
VLAN support | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Power connector | DC-in jack |
MAC Address Table | 8000 entries |
Packet buffer memory | 2 MB |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Packet forwarding rate (10 Mbps) | 14880 pps |
Forwarding rate | 23.8 Mpps |
Packet forwarding rate (100 Mbps) | 148800 pps |
Jumbo frames | 10000 |
Jumbo Frames support | Yes |
Switching capacity | 32 Gbit/s |
Power Over Ethernet (PoE) | No |
