Certification | CE, FCC ,RoHS |
LED indicators | Yes |
Housing material | Steel |
Rack mounting | No |
Product colour | Black |
Power source | DC |
Input current | 1 A |
Power consumption (max) | 10 W |
Input voltage | 12 V |
Power supply included | Yes |
IGMP snooping | Yes |
Heat dissipation | 34.12 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Depth | 111.7 mm |
Width | 286 mm |
Height | 25.4 mm |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
Networking standards | IEEE 802.3x |
Full duplex | Yes |
Copper ethernet cabling technology | 1000BASE-T |
10G support | No |
Flow control support | Yes |
Plug and Play | Yes |
Package width | 170 mm |
Quick start guide | Yes |
Package height | 70 mm |
PACKAGE WEIGHT | 1.33 kg |
Package depth | 412 mm |
Package Type | Box |
AC adapter included | Yes |
Rubber feet | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Gigabit Ethernet (copper) ports quantity | 16 |
Harmonized System (HS) code | 85176990 |
Packet buffer memory | 4.1 MB |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Store-and-forward | Yes |
Switching capacity | 32 Gbit/s |
Jumbo frames | 10000 |
Forwarding rate | 23.8 Mpps |
Power Over Ethernet (PoE) | No |
