Product colour | Black |
LED indicators | Yes |
Housing material | Metal |
Wall mountable | Yes |
Stackable | Yes |
Input current | 0.6 A |
AC input voltage | 220 V |
AC input frequency | 50 Hz |
Power consumption (typical) | 11.72 W |
DC input voltage | 9 V |
Power consumption (max) | 144.28 W |
Power supply included | Yes |
IGMP snooping | Yes |
Loop protection | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 490.55 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Depth | 111.7 mm |
Width | 286 mm |
Height | 25.4 mm |
Networking standards | IEEE 802.3u |
Number of VLANs | 32 |
VLAN support | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Auto MDI/MDI-X | Yes |
Cable types supported | Cat5 |
Flow control support | Yes |
Port mirroring | Yes |
Full duplex | Yes |
Virtual LAN features | Protocol-based VLAN |
Cable length detection | Yes |
Rate limiting | Yes |
Auto-negotiation | Yes |
Broadcast storm control | Yes |
Link aggregation | Yes |
Package depth | 434 mm |
Package height | 70 mm |
PACKAGE WEIGHT | 2 kg |
Package width | 227 mm |
Quick start guide | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Gigabit Ethernet (copper) ports quantity | 16 |
Packet buffer memory | 4.1 MB |
Jumbo Frames support | Yes |
MAC Address Table | 8000 entries |
Switching capacity | 32 Gbit/s |
Number of queues | 4 |
Forwarding rate | 23.81 Mpps |
Store-and-forward | Yes |
Jumbo frames | 9000 |
Power Over Ethernet (PoE) | Yes |
Warnings | Do not open the case or try to repair it yourself. |
