LED indicators | Yes |
Product colour | Black |
Rack mounting | Yes |
Housing material | Metal |
Form factor | 1U |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power source | AC |
Power consumption (max) | 19.15 W |
Power supply included | Yes |
IGMP snooping | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 34.52 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Switch layer | L2 |
Height | 44 mm |
Depth | 180 mm |
Width | 284 mm |
Networking standards | IEEE 802.3 |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Copper ethernet cabling technology | 100BASE-TX |
10G support | No |
Flow control support | Yes |
Number of VLANs | 32 |
Port mirroring | Yes |
Auto-negotiation | Yes |
Cable types supported | Cat3 |
Broadcast storm control | Yes |
Virtual LAN features | Tagged VLAN |
Rate limiting | Yes |
Link aggregation | Yes |
Compatible operating systems | Windows |
Maximum cable length | 100 m |
Package Type | Box |
User guide | Yes |
Package width | 250 mm |
Package height | 80 mm |
PACKAGE WEIGHT | 1.91 kg |
Package depth | 400 mm |
CABLES INCLUDED | AC |
Resource CD | Yes |
Rack mount kit | Yes |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 16 |
Jumbo Frames support | Yes |
MAC Address Table | 8000 entries |
Switching capacity | 32 Gbit/s |
Packet buffer memory | 0.512 MB |
Number of queues | 4 |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Forwarding rate | 23.8 Mpps |
Power Over Ethernet (PoE) | No |
Sustainability certificates | Federal Communications Commission (FCC) |
Sustainability compliance | Yes |
