Rack mounting | Yes |
Product colour | Black |
Stackable | No |
Housing material | Metal |
Form factor | 1U |
Number of fans | 1 fan(s) |
LED indicators | Yes |
Power supply included | Yes |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power source | AC/PoE |
Power consumption (max) | 124.4 W |
IGMP snooping | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Switch layer | L2 |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Height | 44 mm |
Depth | 180 mm |
Width | 294 mm |
Copper ethernet cabling technology | 100BASE-TX |
Port mirroring | Yes |
Cable types supported | Cat4 |
Virtual LAN features | Port-based VLAN |
Networking standards | IEEE 802.3ab |
Link aggregation | Yes |
Auto-negotiation | Yes |
Broadcast storm control | Yes |
Flow control support | Yes |
10G support | No |
VLAN support | Yes |
Auto MDI/MDI-X | Yes |
Number of VLANs | 4000 |
Compatible operating systems | Windows |
Maximum cable length | 100 m |
User guide | Yes |
PACKAGE WEIGHT | 2.28 kg |
Package height | 80 mm |
Resource CD | Yes |
Package depth | 400 mm |
CABLES INCLUDED | AC |
Package Type | Box |
Rack mount kit | Yes |
Package width | 250 mm |
Gigabit Ethernet (copper) ports quantity | 16 |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Packet buffer memory | 4.1 MB |
Store-and-forward | Yes |
Switching capacity | 32 Gbit/s |
Jumbo frames | 10000 |
MAC Address Table | 8000 entries |
Forwarding rate | 23.8 Mpps |
Number of queues | 4 |
Jumbo Frames support | Yes |
Total Power over Ethernet (PoE) budget | 110 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Sustainability certificates | CE |
Sustainability compliance | Yes |
