Rack mounting | Yes |
Product colour | Black |
LED indicators | Yes |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 9.26 W |
AC input frequency | 50/60 Hz |
DHCP features | DHCP snooping |
PASSWORD PROTECTION | Yes |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
Security algorithms | 802.1x RADIUS |
Static port security | Yes |
Heat dissipation | 31.6 BTU/h |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Switch type | Unmanaged |
Switch layer | L2 |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Traffic shaping | Yes |
Configuring Location Settings (CLI) | Yes |
Traffic classification | Yes |
Cloud-managed | Yes |
System event log | Yes |
User operation log | Yes |
Height | 44 mm |
Width | 440 mm |
Depth | 180 mm |
Full duplex | Yes |
Flow control support | Yes |
Port mirroring | Yes |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Copper ethernet cabling technology | 100BASE-TX |
Ethernet LAN data rates | 1000 Mbit/s |
Networking standards | IEEE 802.3i |
Cable types supported | Cat3 |
Auto-negotiation | Yes |
IP routing | Yes |
Head-of-line (HOL) blocking | Yes |
Policy-based routing | Yes |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Jumbo Frames support | Yes |
Switching capacity | 32 Gbit/s |
MAC Address Table | 8000 entries |
Jumbo frames | 10000 |
Store-and-forward | Yes |
Forwarding rate | 23.8 Mpps |
