Certification | FCC, CE, RoHS |
Rack mounting | Yes |
LED indicators | Yes |
Product colour | Grey |
Stackable | Yes |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power source | AC |
Power consumption (max) | 13.62 W |
Power supply included | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 32 - 104 °F |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 46.44 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Width | 294 mm |
Height | 44 mm |
Depth | 180 mm |
10G support | No |
Auto-negotiation | Yes |
Cable types supported | Cat3 |
Flow control support | Yes |
Networking standards | IEEE 802.3ab |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
PACKAGE WEIGHT | 1.95 kg |
Package width | 250 mm |
Package depth | 400 mm |
Package height | 80 mm |
Package Type | Box |
User guide | Yes |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Supported network protocols | CSMA/CD, TCP/IP |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Gigabit Ethernet (copper) ports quantity | 24 |
Dimensions (WxDxH) | 294 x 180 x 44 mm |
Connectivity Technology | Wired |
Connectivity LEDs | Y |
Bandwidth | 48 Gbit/s |
Power requirements | 100 - 240V, 50/60Hz |
Networking Features | Gigabit Ethernet |
Harmonized System (HS) code | 85176990 |
Forwarding rate | 35.7 Mpps |
MAC Address Table | 8000 entries |
Store-and-forward | Yes |
Switching capacity | 48 Gbit/s |
Jumbo frames | 10000 |
Maximum data transfer rate | 1 Gbit/s |
Supported data transfer rates | 10/100/100 Mbps |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | No |
