Certification | FCC, CE, RoHS |
LED indicators | Yes |
Product colour | Black |
Rack mounting | Yes |
Form factor | 1U |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power supply included | Yes |
Power consumption (max) | 14.86 W |
Power source | AC |
IGMP snooping | Yes |
Loop protection | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Heat dissipation | 114.37 BTU/h |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Managed |
Depth | 180 mm |
Width | 294 mm |
Height | 44 mm |
Networking standards | IEEE 802.3 |
Link aggregation | Yes |
Flow control support | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Number of VLANs | 32 |
Copper ethernet cabling technology | 1000BASE-T |
Port mirroring | Yes |
Broadcast storm control | Yes |
Virtual LAN features | Tagged VLAN |
VLAN support | Yes |
Auto-negotiation | Yes |
Cable types supported | Cat6 |
Rate limiting | Yes |
Package Type | Box |
PACKAGE WEIGHT | 2.02 kg |
Rack mount kit | Yes |
Package height | 80 mm |
Package depth | 400 mm |
User guide | Yes |
Package width | 250 mm |
CABLES INCLUDED | AC |
Gigabit Ethernet (copper) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Harmonized System (HS) code | 85176990 |
Jumbo Frames support | Yes |
Jumbo frames | 9216 |
Number of queues | 4 |
Switching capacity | 48 Gbit/s |
Forwarding rate | 35.7 Mpps |
MAC Address Table | 8000 entries |
Packet buffer memory | 0.512 MB |
