Certification | FCC, CE, RoHS |
Form factor | 1U |
Product colour | Black |
LED indicators | Yes |
Rack mounting | Yes |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power consumption (max) | 13.62 W |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 46.44 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Depth | 180 mm |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.3x |
Auto MDI/MDI-X | Yes |
Full duplex | Yes |
10G support | No |
Flow control support | Yes |
Copper ethernet cabling technology | 10BASE-T |
Auto-negotiation | Yes |
Half duplex | Yes |
PACKAGE WEIGHT | 2.13 kg |
CABLES INCLUDED | AC |
Package height | 80 mm |
Package width | 250 mm |
Package depth | 528 mm |
User guide | Yes |
Rack mount kit | Yes |
Supported network protocols | CSMA/CD, TCP/IP |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Gigabit Ethernet (copper) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Connectivity Technology | Wired |
Connectivity LEDs | Y |
Dimensions (W x D x H) (imperial) | 439.4 x 180.3 x 43.2 mm (17.3 x 7.1 x 1.7") |
Bandwidth | 48 Gbit/s |
Supported data transfer rates | 10/100/1000 Mbps |
Jumbo Frames support | Yes |
Switching capacity | 48 Gbit/s |
MAC Address Table | 8000 entries |
Forwarding rate | 35.7 Mpps |
Maximum data transfer rate | 1 Gbit/s |
Store-and-forward | Yes |
Jumbo frames | 10000 |
