Certification | CE, FCC, RoHS |
Product colour | Blue |
LED indicators | Power |
Wall mountable | Yes |
Housing material | Metal |
Rack mounting | No |
Power supply included | Yes |
Power consumption (max) | 2.776 W |
Input voltage | 5 V |
Input current | 0.6 A |
Power source | DC |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 9.466 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Width | 99.8 mm |
Height | 25 mm |
Depth | 98 mm |
Auto-negotiation | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3x |
Package depth | 128 mm |
Quick start guide | Yes |
Package width | 125 mm |
Package height | 92 mm |
PACKAGE WEIGHT | 290 g |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 5 |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Harmonized System (HS) code | 85176990 |
Forwarding rate | 7.4 Mpps |
Switching capacity | 10 Gbit/s |
MAC Address Table | 2000 entries |
Packet buffer memory | 1 MB |
Jumbo Frames support | Yes |
Jumbo frames | 16000 |
Power Over Ethernet (PoE) | No |
