Certification | CE, FCC, RoHS |
Product colour | Black |
LED indicators | Yes |
Input current | 0.6 A |
Power supply included | Yes |
Input voltage | 9 V |
Power consumption (max) | 2.3 W |
Power source | DC |
IGMP snooping | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 7.83 BTU/h |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Width | 100 mm |
Height | 25 mm |
Depth | 98 mm |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3u |
Flow control support | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Full duplex | Yes |
Auto-negotiation | Yes |
10G support | No |
Rack mount kit | Yes |
User guide | Yes |
PACKAGE WEIGHT | 370 g |
Package depth | 128 mm |
Package height | 92 mm |
Package width | 125 mm |
Package Type | Box |
Switching protocols | CSMA/CD |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 5 |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Ethernet LAN | Yes |
Connectivity Technology | Wired |
Wi-Fi | No |
Power LED | Yes |
MAC Address Table | 2000 entries |
Jumbo Frames support | Yes |
Maximum data transfer rate | 2 Gbit/s |
Jumbo frames | 16000 |
Packet buffer memory | 1 MB |
Forwarding rate | 7.4 Mpps |
Supported data transfer rates | 10/100/1000Mbps |
Switching capacity | 10 Gbit/s |
Store-and-forward | Yes |
Power Over Ethernet (PoE) | No |
