Rack mounting | No |
Stackable | No |
Product colour | Black |
LED indicators | Yes |
Power consumption (max) | 64.44 W |
Power source | DC/PoE |
Input current | 1.25 A |
DC input voltage | 48 V |
Power supply included | Yes |
IGMP snooping | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Heat dissipation | 219.87 BTU/h |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Width | 99.8 mm |
Height | 25 mm |
Depth | 98 mm |
Networking standards | IEEE 802.3u |
Copper ethernet cabling technology | 10BASE-T |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
MAC address auto-learning supported | Yes |
Flow control support | Yes |
10G support | No |
MAC address auto-aging supported | Yes |
Cable types supported | Cat5 |
Fanless | Yes |
Maximum cable length | 100 m |
Package Type | Box |
Package height | 121 mm |
PACKAGE WEIGHT | 800 g |
Package depth | 196 mm |
User guide | Yes |
AC adapter included | Yes |
Package width | 131 mm |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 5 |
Harmonized System (HS) code | 85176990 |
Forwarding rate | 7.44 Mpps |
MAC Address Table | 2000 entries |
Store-and-forward | Yes |
Switching capacity | 10 Gbit/s |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 56 W |
Power over Ethernet (PoE) ports quantity | 4 |
Sustainability certificates | CE |
Sustainability compliance | Yes |
