Certification | CE, FCC, RoHS |
LED indicators | Activity |
Product colour | Blue |
Rack mounting | No |
Input voltage | 5 V |
Power source | DC |
Input current | 0.6 A |
Power consumption (max) | 3.7 W |
Power supply included | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 12.617 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Width | 158 mm |
Depth | 99 mm |
Height | 25 mm |
Networking standards | IEEE 802.3ab |
10G support | No |
Auto MDI/MDI-X | Yes |
Flow control support | Yes |
Auto-negotiation | Yes |
Quick start guide | Yes |
Package width | 130 mm |
PACKAGE WEIGHT | 470 g |
Package depth | 191 mm |
Package height | 92 mm |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 8 |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 4000 entries |
Switching capacity | 16 Gbit/s |
Jumbo Frames support | Yes |
Forwarding rate | 11.9 Mpps |
Packet buffer memory | 1.5 MB |
Jumbo frames | 16000 |
Power Over Ethernet (PoE) | No |
