Product colour | Grey |
LED indicators | Yes |
Stackable | No |
Housing material | Metal |
Rack mounting | No |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Input current | 1.31 A |
Power source | DC/PoE |
Power consumption (max) | 75 W |
Number of power supply units | 1 |
DC input voltage | 53.5 V |
Power supply included | Yes |
IGMP snooping | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 225.75 BTU/h |
Quality of Service (QoS) support | No |
Switch type | Managed |
Height | 27 mm |
Depth | 98 mm |
Width | 171 mm |
Networking standards | IEEE 802.3af |
Copper ethernet cabling technology | 100BASE-TX |
Auto-negotiation | Yes |
Auto MDI/MDI-X | Yes |
Flow control support | Yes |
10G support | No |
MAC address auto-aging supported | Yes |
MAC address auto-learning supported | Yes |
Cable types supported | Cat5 |
Maximum cable length | 100 m |
Fanless | Yes |
Package Type | Box |
PACKAGE WEIGHT | 900 g |
Package width | 223 mm |
CABLES INCLUDED | AC |
User guide | Yes |
Package height | 68 mm |
Package depth | 280 mm |
Power connector | DC-in jack |
Gigabit Ethernet (copper) ports quantity | 8 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
MAC Address Table | 4000 entries |
Switching capacity | 16 Gbit/s |
Jumbo Frames support | Yes |
Jumbo frames | 16000 |
Store-and-forward | Yes |
Forwarding rate | 11.904 Mpps |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Total Power over Ethernet (PoE) budget | 64 W |
Sustainability compliance | Yes |
Sustainability certificates | CE |
