Product colour | Black |
Form factor | 1U |
LED indicators | Yes |
Rack mounting | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power supply included | Yes |
Power consumption (typical) | 4.3 W |
Power source | AC |
Heat dissipation | 14.67 BTU/h |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Switch type | Unmanaged |
Depth | 180 mm |
Height | 44 mm |
Width | 294 mm |
Auto-negotiation | Yes |
Flow control support | Yes |
Networking standards | IEEE 802.3x |
10G support | No |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 10BASE-T |
Full duplex | Yes |
Package Type | Box |
PACKAGE WEIGHT | 1.7 kg |
Package width | 400 mm |
Package height | 80 mm |
Package depth | 250 mm |
Quick start guide | Yes |
CABLES INCLUDED | AC |
Supported network protocols | CSMA/CD, TCP/IP |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Dimensions (W x D x H) (imperial) | 248.9 x 157.5 x 43.2 mm (9.8 x 6.2 x 1.7") |
Bandwidth | 16 Gbit/s |
Networking Features | Gigabit Ethernet |
Connectivity Technology | Wired |
Dimensions (WxDxH) | 294 x 180 x 44 mm |
Input Frequency | 50 - 60 Hz |
Connectivity LEDs | Y |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 4000 entries |
Jumbo frames | 16000 |
Store-and-forward | Yes |
Supported data transfer rates | 10/100/1000 Mbps |
Switching capacity | 16 Gbit/s |
Jumbo Frames support | Yes |
Maximum data transfer rate | 1 Gbit/s |
Power Over Ethernet (PoE) | No |
