Certification | FCC, CE, RoHS |
Product colour | Black |
LED indicators | PoE |
Input voltage | 48 V |
Power source | DC |
Power consumption (max) | 65.2 W |
Power supply included | Yes |
Input current | 1.25 A |
Loop protection | Yes |
IGMP snooping | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 256.19 BTU/h |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Switch layer | L2 |
Depth | 101 mm |
Width | 158 mm |
Height | 25 mm |
Networking standards | IEEE 802.3u |
Number of VLANs | 32 |
10G support | No |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Cable types supported | Cat4 |
Port mirroring | Yes |
Virtual LAN features | Port-based VLAN |
Link aggregation | Yes |
Auto-negotiation | Yes |
Broadcast storm control | Yes |
User guide | Yes |
Package depth | 196 mm |
Package Type | Box |
Package height | 121 mm |
Package width | 131 mm |
PACKAGE WEIGHT | 890 g |
CABLES INCLUDED | AC |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 8 |
Harmonized System (HS) code | 85176990 |
Jumbo Frames support | Yes |
Switching capacity | 16 Gbit/s |
Store-and-forward | Yes |
MAC Address Table | 4000 entries |
Forwarding rate | 11.9 Mpps |
Jumbo frames | 15000 |
Packet buffer memory | 1.5 MB |
Power over Ethernet (PoE) power per port | 15.4 W |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 64 W |
Power over Ethernet (PoE) ports quantity | 4 |
