| Certification | FCC, CE, RoHS |
| LED indicators | Power |
| Product colour | Black |
| Power supply included | Yes |
| Input voltage | 48 V |
| Power source | DC |
| Power consumption (max) | 65.2 W |
| Input current | 1.25 A |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Heat dissipation | 256.19 BTU/h |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Switch layer | L2 |
| Depth | 101 mm |
| Height | 25 mm |
| Width | 158 mm |
| Networking standards | IEEE 802.1Q |
| 10G support | No |
| Number of VLANs | 32 |
| Cable types supported | Cat5 |
| Auto-negotiation | Yes |
| Port mirroring | Yes |
| VLAN support | Yes |
| Auto MDI/MDI-X | Yes |
| Virtual LAN features | Port-based VLAN |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Package width | 131 mm |
| Package Type | Box |
| Package height | 121 mm |
| PACKAGE WEIGHT | 890 g |
| CABLES INCLUDED | AC |
| User guide | Yes |
| Package depth | 196 mm |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Harmonized System (HS) code | 85176990 |
| Switching capacity | 16 Gbit/s |
| Jumbo frames | 15000 |
| Packet buffer memory | 1.5 MB |
| Jumbo Frames support | Yes |
| Forwarding rate | 11.9 Mpps |
| MAC Address Table | 4000 entries |
| Store-and-forward | Yes |
| Total Power over Ethernet (PoE) budget | 64 W |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Power Over Ethernet (PoE) | Yes |
