Certification | CE, FCC, RoHS |
Product colour | Black |
Rack mounting | Yes |
Number of fans | 2 fan(s) |
Form factor | 1U |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
Power source | AC |
Power consumption (max) | 217.22 W |
IGMP snooping | Yes |
Security algorithms | SNMPv2 |
Loop protection | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 50 °C |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 741.15 BTU/h |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Switch layer | L2 |
Height | 44 mm |
Width | 440 mm |
Depth | 180 mm |
Networking standards | IEEE 802.3u |
VLAN support | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Port mirroring | Yes |
Auto MDI/MDI-X | Yes |
Number of VLANs | 32 |
Rate limiting | Yes |
Auto-negotiation | Yes |
Flow control support | Yes |
10G support | No |
Broadcast storm control | Yes |
Link aggregation | Yes |
Virtual LAN features | Port-based VLAN |
Cable types supported | Cat6 |
Package height | 80 mm |
Package depth | 528 mm |
User guide | Yes |
PACKAGE WEIGHT | 2.91 kg |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Package width | 250 mm |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Gigabit Ethernet (copper) ports quantity | 16 |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Switching capacity | 36 Gbit/s |
Packet buffer memory | 4.1 MB |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Jumbo frames | 9000 |
Forwarding rate | 23.8 Mpps |
Number of queues | 4 |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 192 W |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Fiber ethernet cabling technology | 1000BASE-X |
