Certification | CE, FCC, RoHS |
Product colour | Black |
Form factor | 1U |
Rack mounting | Yes |
LED indicators | Yes |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power source | DC/PoE |
Power supply included | Yes |
MAC address filtering | Yes |
BPDU filtering/protection | Yes |
DHCP features | DHCP client |
SSH/SSL support | Yes |
Authentication | MAC-based authentication, Port-based authentication |
Loop protection | Yes |
Access Control List (ACL) | Yes |
Static port security | Yes |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Web-based management | Yes |
ARP inspection | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L2/L2+ |
System event log | Yes |
Configuring Location Settings (CLI) | Yes |
Cloud-managed | Yes |
Depth | 180 mm |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.1x |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
10G support | No |
Rate limiting | Yes |
Flow control support | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Spanning tree protocol | Yes |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Auto-negotiation | Yes |
Policy-based routing | Yes |
IP routing | Yes |
User guide | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Package Type | Box |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Switching capacity | 26.78 Gbit/s |
Jumbo frames | 9 |
Forwarding rate | 26.78 Mpps |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 150 W |
Multicast support | Yes |
Multicast features | Multicast forwarding |
