Rack mounting | Yes |
Form factor | 1U |
Product colour | Black |
LED indicators | Yes |
Power source | AC |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (max) | 6.84 W |
Power supply included | Yes |
MAC address filtering | Yes |
DHCP features | DHCPv6 snooping |
IGMP snooping | Yes |
Authentication type | RADIUS |
BPDU filtering/protection | Yes |
SSH/SSL support | Yes |
Authentication | MAC-based authentication, Port-based authentication |
Loop protection | Yes |
IP-MAC-Port binding | Yes |
Access Control List (ACL) | Yes |
Static port security | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Cloud-managed | Yes |
Configuring Location Settings (CLI) | Yes |
ARP inspection | Yes |
Switch layer | L2/L3 |
MIB support | Yes |
System event log | Yes |
Switch type | Managed |
Width | 294 mm |
Depth | 180 mm |
Height | 44 mm |
VLAN support | Yes |
Networking standards | IEEE 802.1x |
10G support | No |
Number of VLANs | 4000 |
Rate limiting | Yes |
Port mirroring | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Head-of-line (HOL) blocking | Yes |
Spanning tree protocol | Yes |
Virtual LAN features | Protocol-based VLAN |
Flow control support | Yes |
IP routing | Yes |
IPv6 routes | 48 |
IPv4 routes | 48 |
Minimum system requirements | Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux. |
Firmware upgradeable | Yes |
Fanless | Yes |
Package height | 80 mm |
Package depth | 250 mm |
Package width | 400 mm |
Manual | Yes |
User guide | Yes |
Quick start guide | Yes |
PACKAGE WEIGHT | 1.9 kg |
Rack mount kit | Yes |
IPv4 & IPv6 features | IPv6 Telnet |
GARP VLAN Registration Protocol (GVRP) | Yes |
Management protocols | SNMPv1/v2c/v3, SNTP |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
SFP module slots quantity | 2 |
console port | RJ-45/micro-USB |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Switching capacity | 20 Gbit/s |
Packet buffer memory | 4.1 MB |
Static route | Yes |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Forwarding rate | 14.9 Mpps |
Number of IP interfaces | 16 |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Multicast Listener Discovery (MLD) snooping | Y |
