Certification | CE, FCC, RoHS |
Form factor | 1U |
LED indicators | Yes |
Product colour | Black |
Rack mounting | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power source | AC |
Power consumption (max) | 12.3 W |
Power supply included | Yes |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
Loop protection | Yes |
SSH/SSL support | Yes |
DHCP features | DHCP server |
BPDU filtering/protection | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 41.97 BTU/h |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
ARP inspection | Yes |
Switch type | Managed |
Switch layer | L2/L2+ |
System event log | Yes |
Cloud-managed | Yes |
MIB support | Yes |
Depth | 180 mm |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.3i |
VLAN support | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
10G support | No |
Number of VLANs | 4000 |
Virtual LAN features | Voice VLAN |
Broadcast storm control | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Rate limiting | Yes |
Port mirroring | Yes |
Flow control support | Yes |
Fanless | Yes |
Quick start guide | Yes |
CABLES INCLUDED | AC |
GARP VLAN Registration Protocol (GVRP) | Yes |
Management protocols | SNMPv1/v2c/v3, SNTP |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Gigabit Ethernet (copper) ports quantity | 16 |
Switching capacity | 36 Gbit/s |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Number of static routes | 32 |
Packet buffer memory | 4.1 MB |
Forwarding rate | 26.8 Mpps |
Number of IP interfaces | 16 |
Static route | Yes |
Power Over Ethernet (PoE) | No |
Multicast Listener Discovery (MLD) snooping | Y |
Multicast support | Yes |
