| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Number of fans | 1 fan(s) |
| Form factor | 1U |
| Power source | AC |
| Power supply included | Yes |
| Power consumption (max) | 35.7 W |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| MAC address filtering | Yes |
| PASSWORD PROTECTION | Yes |
| DHCP features | DHCP server |
| IGMP snooping | Yes |
| IP-MAC-Port binding | Yes |
| Loop protection | Yes |
| Access Control List (ACL) | Yes |
| IGMP proxy | Yes |
| Authentication type | AAA, RADIUS, TACACS+ |
| BPDU filtering/protection | Yes |
| SSH/SSL support | Yes |
| Queue scheduling algorithms | WRR+SP |
| Authentication | Auto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Heat dissipation | 121.81 BTU/h |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| MIB support | RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925 |
| Cloud-managed | Yes |
| System event log | Yes |
| Switch layer | L2+ |
| Configuring Location Settings (CLI) | Yes |
| ARP inspection | Yes |
| Width | 440 mm |
| Height | 44 mm |
| Depth | 220 mm |
| VLAN support | Yes |
| Networking standards | IEEE 802.1ab |
| Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
| 10G support | Yes |
| Number of VLANs | 4000 |
| IP routing | Yes |
| Active link detection | Yes |
| Rate limiting | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Head-of-line (HOL) blocking | Yes |
| Routing entries | 512 |
| Virtual LAN features | Private VLAN |
| IPv4 routes | 48 |
| Flow control support | Yes |
| IPv6 routes | 48 |
| Policy-based routing | Yes |
| CABLES INCLUDED | AC |
| Manual | Yes |
| Rack mount kit | Yes |
| IPv4 & IPv6 features | IPv6 Telnet |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| Fiber ports quantity | 20 |
| Basic switching RJ-45 Ethernet ports type | No |
| Power connector | AC-in jack |
| Fiber optic connector | SFP |
| Combo SFP ports quantity | 4 |
| SFP+ module slots quantity | 4 |
| console port | RJ-45/Micro-USB |
| Switching capacity | 128 Gbit/s |
| Jumbo Frames support | Yes |
| Packet buffer memory | 12 MB |
| MAC Address Table | 16000 entries |
| Forwarding rate | 95.23 Mpps |
| Number of static routes | 48 |
| Store-and-forward | Yes |
| Static route | Yes |
| Jumbo frames | 9000 |
| Power Over Ethernet (PoE) | No |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | Y |
