Certification | CE, FCC, RoHS |
LED indicators | Yes |
Product colour | Black |
Rack mounting | Yes |
AC input voltage | 220 V |
Power supply included | Yes |
AC input frequency | 50/60 Hz |
Power consumption (max) | 15.46 W |
Power source | AC |
Loop protection | Yes |
Access Control List (ACL) | Yes |
Security algorithms | SSH |
MAC address filtering | Yes |
Static port security | Yes |
Authentication | Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication |
IGMP snooping | Yes |
SSH/SSL support | Yes |
Queue scheduling algorithms | SP |
IP-MAC-Port binding | Yes |
Authentication type | AAA, TACACS+ |
DHCP features | DHCPv6 snooping |
BPDU filtering/protection | Yes |
Heat dissipation | 52.75 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 45 °C |
Switch type | Managed |
MIB support | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
System event log | Yes |
Traffic classification | Yes |
Configuring Location Settings (CLI) | Yes |
ARP inspection | Yes |
Switch layer | L2/L3 |
Cloud-managed | Yes |
Depth | 180 mm |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.1Q |
10G support | Yes |
Virtual LAN features | Voice VLAN |
Number of VLANs | 4000 |
VLAN support | Yes |
IP routing | Yes |
Broadcast storm control | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Rate limiting | Yes |
Port mirroring | Yes |
Head-of-line (HOL) blocking | Yes |
Spanning tree protocol | Yes |
Manual | Yes |
Quick start guide | Yes |
Rack mount kit | Yes |
CABLES INCLUDED | AC |
Package Type | Box |
Management protocols | SNMPv1/v2c/v3, SNTP |
IPv4 & IPv6 features | IPv6 tracert |
SFP+ module slots quantity | 8 |
Basic switching RJ-45 Ethernet ports type | No |
Power connector | DC-in jack |
console port | RJ-45/Micro-USB |
Forwarding rate | 119.04 Mpps |
Switching capacity | 160 Gbit/s |
Jumbo Frames support | Yes |
Number of queues | 8 |
Static route | Yes |
MAC Address Table | 32000 entries |
Jumbo frames | 9000 |
Packet buffer memory | 16 MB |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Multicast Listener Discovery (MLD) snooping | Y |
