Rack mounting | Yes |
Product colour | Black |
AC input frequency | 50/60 Hz |
Power source | AC |
Surge protection | Yes |
Surge protection voltage | 6 kV |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
DHCP features | DHCP client |
Queue scheduling algorithms | Weighted Round Robin (WRR) |
IGMP snooping | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | -5 - 50 °C |
Storage relative humidity (H-H) | 5 - 90% |
Cloud-managed | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Switch layer | L2 |
Web-based management | Yes |
Unified static configuration | Yes |
Depth | 140 mm |
Width | 294 mm |
Height | 44 mm |
Link aggregation | Yes |
Flow control support | Yes |
Fast leave | Yes |
Virtual LAN features | Port-based VLAN |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
Number of VLANs | 32 |
Broadcast storm control | Yes |
VLAN support | Yes |
Port mirroring | Yes |
Fanless | Yes |
Firmware upgradeable | Yes |
User guide | Yes |
Rack mount kit | No |
CABLES INCLUDED | AC |
Compliance certificates | Federal Communications Commission (FCC) |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Switching capacity | 48 Gbit/s |
Forwarding rate | 35.7 Mpps |
Packet buffer memory | 4 MB |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Jumbo frames | 15000 |
Store-and-forward | Yes |
Multicast support | Yes |
