| management functions | |
| Switch-Typ | Unmanaged |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 16 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports | 16 |
| network | |
| mesh standard | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-T |
| supported cable types | Cat3, Cat4, Cat5, Cat5e |
| Eigenschaft | Nachhaltigkeitskonformität |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| data transmission | |
| Routing/Switching Capacity | 3,2 Gbit/s |
| passage | 2,38 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Data packet buffer memory | 2 MB |
| safety | |
| logs | |
| Supported network protocols | TCP/IP |
| Design | |
| form factor | 1U |
| Product color | Schwarz |
| housing material | Metall |
| number of fans | 0 Lüfter |
| Services | |
| energy | |
| energy source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max.) | 2,06 W |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| heat dissipation | 7,03 BTU/h |
| weight and dimensions | |
| broad | 294 mm |
| depth | 180 mm |
| height | 44 mm |
| scope of delivery | |
| Supplied cables | AC |
| package weight | 1,95 kg |
| sustainability | |
| certificates | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
| certification | FCC, RoHS |
