| management functions | |
| Switch-Typ | Unmanaged |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 6 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
| network | |
| mesh standard | IEEE 802.3af, IEEE 802.3at |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 100BASE-T |
| supported cable types | Cat3, Cat4, Cat5, Cat5e |
| Eigenschaft | Nachhaltigkeitskonformität |
| data transmission | |
| Routing/Switching Capacity | 1,2 Gbit/s |
| Transferrate | 0,8928 Mpps |
| MAC-Adressentabelle | 2000 Eintragungen |
| Jumbo-Frames | 2000 |
| Design | |
| Product color | Schwarz |
| housing material | Metall |
| Services | |
| energy | |
| energy source | DC/PoE |
| AC input voltage | 220 V |
| AC input frequency | 50 Hz |
| DC input voltage | 53.5 V |
| input current | 1.31 A |
| Power consumption (max.) | 74 W |
| Power Over Ethernet (PoE) | |
| Number of Power over Ethernet plus (PoE+) ports | 4 |
| Overall Power over Ethernet (PoE) | 67 W |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| heat dissipation | 252,34 BTU/h |
| weight and dimensions | |
| broad | 158 mm |
| depth | 101 mm |
| height | 25 mm |
| scope of delivery | |
| packaging type | Box |
| package weight | 870 g |
| sustainability | |
| certificates | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
| certification | FCC, CE, RoHS |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
