Certification | FCC, CE, RoHS |
LED indicators | Yes |
Housing material | Metal |
Stackable | No |
Product colour | Black |
Rack mounting | No |
DC input voltage | 53.5 V |
Input current | 1.31 A |
Power source | DC/PoE |
AC input voltage | 220 V |
Power consumption (max) | 74 W |
Power supply included | Yes |
AC input frequency | 50 Hz |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 252.34 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch type | Unmanaged |
Width | 158 mm |
Depth | 101 mm |
Height | 25 mm |
MAC address auto-aging supported | Yes |
Auto-negotiation | Yes |
Copper ethernet cabling technology | 10BASE-T |
Full duplex | Yes |
MAC address auto-learning supported | Yes |
Cable types supported | Cat5 |
Networking standards | IEEE 802.3af |
Flow control support | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Half duplex | Yes |
Fanless | Yes |
Package depth | 196 mm |
Package Type | Box |
Package height | 121 mm |
User guide | Yes |
Package width | 131 mm |
PACKAGE WEIGHT | 870 g |
AC adapter included | Yes |
Basic switching RJ-45 Ethernet ports quantity | 6 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 2000 entries |
Switching capacity | 1.2 Gbit/s |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Jumbo frames | 2000 |
Forwarding rate | 0.8928 Mpps |
Total Power over Ethernet (PoE) budget | 67 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet plus (PoE+) ports quantity | 4 |
Sustainability certificates | RoHS |
Sustainability compliance | Yes |
