Rack mounting | No |
Stackable | No |
Wall mountable | Yes |
Housing material | Metal |
Product colour | Black |
LED indicators | Yes |
Power source | DC/PoE |
DC input voltage | 53.5 V |
AC input frequency | 50 Hz |
Power supply included | No |
Power consumption (max) | 47.1 W |
AC input voltage | 220 V |
Input current | 0.81 A |
DHCP features | DHCPv6 relay |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Heat dissipation | 160.61 BTU/h |
Switch type | Unmanaged |
Height | 27 mm |
Width | 171 mm |
Depth | 98 mm |
MAC address auto-aging supported | Yes |
Flow control support | Yes |
10G support | No |
Networking standards | IEEE 802.3af |
MAC address auto-learning supported | Yes |
Auto MDI/MDI-X | Yes |
Half duplex | Yes |
Auto-negotiation | Yes |
Copper ethernet cabling technology | 100BASE-TX |
Full duplex | Yes |
Fanless | Yes |
PACKAGE WEIGHT | 750 g |
CABLES INCLUDED | AC |
Package height | 68 mm |
User guide | Yes |
Package width | 223 mm |
AC adapter included | Yes |
Package depth | 280 mm |
Routing protocols | OSPF |
IPv4 & IPv6 features | IPv6 portal |
Fast Ethernet (copper) ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Power connector | DC-in jack |
Bandwidth | 1.6 Gbit/s |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 2000 entries |
Jumbo Frames support | Yes |
Jumbo frames | 2000 |
Switching capacity | 1.6 Gbit/s |
Forwarding rate | 1.1904 Mpps |
Store-and-forward | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Total Power over Ethernet (PoE) budget | 41 W |
Power Over Ethernet (PoE) | Yes |
Sustainability certificates | RoHS |
Sustainability compliance | Yes |
