Rack mounting | Yes |
LED indicators | Yes |
Product colour | Grey |
Stackable | No |
Housing material | Metal |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 3.53 W |
Power source | AC |
Power supply included | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 10.88 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Switch type | Unmanaged |
Width | 294 mm |
Height | 44 mm |
Depth | 180 mm |
Ethernet LAN data rates | 10,100 Mbit/s |
Copper ethernet cabling technology | 100BASE-TX |
10G support | No |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3u |
Cable types supported | Cat3 |
Fanless | Yes |
User guide | Yes |
Package depth | 400 mm |
PACKAGE WEIGHT | 2 kg |
Package height | 80 mm |
Package width | 250 mm |
CABLES INCLUDED | AC |
Package Type | Box |
Rack mount kit | Yes |
Supported network protocols | CSMA/CD, TCP/IP |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Fast Ethernet (copper) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Harmonized System (HS) code | 85176990 |
Switching capacity | 4.8 Gbit/s |
Forwarding rate | 3.57 Mpps |
Throughput | 3.57 Mpps |
Store-and-forward | Yes |
MAC Address Table | 8000 entries |
Packet buffer memory | 2 MB |
Power Over Ethernet (PoE) | No |
Sustainability certificates | CE |
Sustainability compliance | Yes |
