| management functions | |
| Switch-Typ | Unmanaged |
| Eigenschaft | Schnellstartübersicht |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 8 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Number of Gigabit Ethernet (copper) ports | 8 |
| network | |
| mesh standard | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| supported cable types | Cat3, Cat4, Cat5, Cat5e |
| data transmission | |
| Transferrate | 11,9 Mpps |
| MAC-Adressentabelle | 4000 Eintragungen |
| Jumbo-Frames | 16000 |
| Data packet buffer memory | 1,5 MB |
| safety | |
| Design | |
| Product color | Schwarz |
| energy | |
| energy source | Gleichstrom |
| input current | 0.6 A |
| input voltage | 9 V |
| Power consumption (max.) | 3,3 W |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| weight and dimensions | |
| broad | 158 mm |
| depth | 101 mm |
| height | 25 mm |
| scope of delivery | |
| Supplied cables | AC |
| packaging type | Box |
| certificates | |
| certification | CE, FCC ,RoHS |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
