| Rack mounting | Yes |
| LED indicators | PoE |
| Product colour | Black |
| Power source | DC/PoE |
| DC input voltage | 53.5 V |
| Power consumption (max) | 146.5 W |
| DHCP features | DHCPv6 snooping |
| Access Control List (ACL) | Yes |
| SSH/SSL support | Yes |
| MAC address entries | Static MAC address entries |
| IGMP snooping | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Queue scheduling algorithms | SP |
| IP-MAC-Port binding | Yes |
| Security algorithms | EAP-MD5 |
| MAC address filtering | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 499.98 BTU/h |
| Quality of Service (QoS) support | Yes |
| MIB support | RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757 |
| Switch type | Managed |
| Cloud-managed | Yes |
| Switch layer | L2/L2+ |
| Configuring Location Settings (CLI) | Yes |
| System event log | Yes |
| ARP inspection | Yes |
| Web-based management | Yes |
| Height | 25.4 mm |
| Width | 286 mm |
| Depth | 111.7 mm |
| Auto MDI/MDI-X | Yes |
| Number of VLANs | 4000 |
| Virtual LAN features | Tagged VLAN |
| Auto-negotiation | Yes |
| Port mirroring | Yes |
| Copper ethernet cabling technology | 100BASE-TX |
| 10G support | No |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Flow control support | Yes |
| Rate limiting | Yes |
| Broadcast storm control | Yes |
| Link aggregation | Yes |
| Networking standards | IEEE 802.1x |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Fanless | Yes |
| Firmware upgradeable | Yes |
| Manual | Yes |
| CABLES INCLUDED | AC |
| Supported network protocols | ICMP, TCPv6, UDPv6, Ping6, Tracert6, Telnet (v6), TFTP, TCP/UDP, DSCP/IP, SSLv3, TLS 1.2 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Forwarding rate | 23.81 Mpps |
| MAC Address Table | 8000 entries |
| Switching capacity | 32 Gbit/s |
| Packet buffer memory | 4.1 MB |
| Jumbo Frames support | Yes |
| Jumbo frames | 9000 |
| Number of queues | 8 |
| Power Over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 120 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
| Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
