Rack mounting | Yes |
LED indicators | PoE |
Product colour | Black |
Power source | DC/PoE |
DC input voltage | 53.5 V |
Power consumption (max) | 146.5 W |
DHCP features | DHCPv6 snooping |
Access Control List (ACL) | Yes |
SSH/SSL support | Yes |
MAC address entries | Static MAC address entries |
IGMP snooping | Yes |
BPDU filtering/protection | Yes |
Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
Queue scheduling algorithms | SP |
IP-MAC-Port binding | Yes |
Security algorithms | EAP-MD5 |
MAC address filtering | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 499.98 BTU/h |
Quality of Service (QoS) support | Yes |
MIB support | RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757 |
Switch type | Managed |
Cloud-managed | Yes |
Switch layer | L2/L2+ |
Configuring Location Settings (CLI) | Yes |
System event log | Yes |
ARP inspection | Yes |
Web-based management | Yes |
Height | 25.4 mm |
Width | 286 mm |
Depth | 111.7 mm |
Auto MDI/MDI-X | Yes |
Number of VLANs | 4000 |
Virtual LAN features | Tagged VLAN |
Auto-negotiation | Yes |
Port mirroring | Yes |
Copper ethernet cabling technology | 100BASE-TX |
10G support | No |
VLAN support | Yes |
Spanning tree protocol | Yes |
Flow control support | Yes |
Rate limiting | Yes |
Broadcast storm control | Yes |
Link aggregation | Yes |
Networking standards | IEEE 802.1x |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Fanless | Yes |
Firmware upgradeable | Yes |
Manual | Yes |
CABLES INCLUDED | AC |
Supported network protocols | ICMP, TCPv6, UDPv6, Ping6, Tracert6, Telnet (v6), TFTP, TCP/UDP, DSCP/IP, SSLv3, TLS 1.2 |
GARP VLAN Registration Protocol (GVRP) | Yes |
IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Forwarding rate | 23.81 Mpps |
MAC Address Table | 8000 entries |
Switching capacity | 32 Gbit/s |
Packet buffer memory | 4.1 MB |
Jumbo Frames support | Yes |
Jumbo frames | 9000 |
Number of queues | 8 |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 120 W |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Multicast support | Yes |
Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
