Housing material | SGCC |
Display type | LCM |
Rack mounting | Yes |
Stackable | Yes |
Product colour | Grey |
LED indicators | Status |
Form factor | 1U |
Reset button | Yes |
Redundant power supply (RPS) support | Yes |
Power supply included | Yes |
Power source | AC/DC |
AC input frequency | 50/60 Hz |
Power consumption (max) | 60 W |
AC input voltage | 100 - 240 V |
IGMP snooping | Yes |
DHCP features | DHCP guarding |
Loop protection | Yes |
Heat dissipation | 102.36 BTU/h |
Operating temperature (T-T) | -5 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch type | Managed |
Switch layer | L2/L3 |
Quality of Service (QoS) support | Yes |
Height | 44 mm |
Width | 442.4 mm |
Depth | 285 mm |
Weight | 4.2 kg |
Number of VLANs | 1000 |
Rate limiting | Yes |
Flow control support | Yes |
VLAN support | Yes |
10G support | Yes |
Virtual LAN features | Voice VLAN |
Broadcast storm control | Yes |
Port mirroring | Yes |
IPv4 routes | 12000 |
Networking standards | IEEE 802.1x |
Rack mount kit | Yes |
CABLES INCLUDED | Power |
Compliance certificates | Federal Communications Commission (FCC) |
SFP+ module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports quantity | 22 |
Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
Power connector | AC/DC |
2.5G Ethernet (copper) ports quantity | 22 |
10G Ethernet (copper) ports quantity | 2 |
Jumbo Frames support | Yes |
Forwarding rate | 171.12 Mpps |
Packet buffer memory | 2 MB |
Static route | Yes |
Switching capacity | 230 Gbit/s |
MAC Address Table | 32000 entries |
Throughput | 115 Gbit/s |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
