network | |
Maximum data transfer rate | 1000 Mbit/s |
mesh standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
Ethernet interfaces type | Gigabit Ethernet |
Ethernet LAN data transfer rates | 1000 Mbit/s |
Ethernet cable cabling technology | 100BASE-FX |
Eigenschaft | Vollduplex |
wiring technology | UTP 3, 4, 5e, 5 |
supported cable types | Cat3, Cat4, Cat5, Cat5e |
Services | |
Maximum possible transmission distance | 20000 m |
wavelength | 1310 nm |
features | |
LED indicators | Leistung, Geschwindigkeit |
Product color | Schwarz |
Compliance with industry standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
connections and interfaces | |
transmission technology | Kabelgebunden |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of fiber connectors | 1 |
Optical cable connector | SC |
energy | |
Power consumption (max.) | 1,52 W |
weight and dimensions | |
broad | 94,5 mm |
depth | 73 mm |
height | 27 mm |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
package weight | 380 g |
certificates | |
certification | FCC, CE |
Other functions | |
Dimensions (WxDxH) | 94,5 x 73 x 27 mm |
More connections | 1x 100M SC1x 100M RJ45 |
