network | |
Maximum data transfer rate | 1000 Mbit/s |
mesh standard | IEEE 802.1ab, IEEE 802.3x, IEEE 802.3z |
Ethernet interfaces type | Gigabit Ethernet |
Ethernet LAN data transfer rates | 1000 Mbit/s |
Eigenschaft | Auto MDI/MDI-X |
Duplex-System | Voll |
supported cable types | Cat6 |
Services | |
Maximum possible transmission distance | 15000 m |
wavelength | 1310 nm |
Kabel mode struktur | Einzelmodus |
features | |
LED indicators | Aktivität, Leistung |
Product color | Schwarz |
connections and interfaces | |
transmission technology | Kabelgebunden |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of fiber connectors | 1 |
Optical cable connector | SC |
energy | |
Power consumption (max.) | 5,5 W |
weight and dimensions | |
broad | 94,5 mm |
depth | 73 mm |
height | 27 mm |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
package weight | 430 g |
certificates | |
Konformitätsbescheinigungen | RoHS |
certification | FCC, CE |
