The Zyxel XMG-100 Series 2.5 Gigabit switch is designed to upgrade and
expand network to a higher speed and better performance network.
It is the most ideal choice for home, SOHO, or small office users who need
more bandwidth for their network with demands coming from online
gaming activities, multimedia streaming services or faster wireless network
connectivity. All ports are equipped with 2.5 Gigabit Ethernet speed, allowing
easy network speed upgrade. In addition, this Series offers an extra SFP+ slot
for high-bandwidth network uplink or access to a Network-Attached Storage
(NAS).
Ports quantity | 6 |
MAC address table, entries | 4K |
Switching capacity, Gbit/s | 45 |
Packet transfer speed | 8 MP |
Ethernet LAN (RJ-45) ports quantity | 4 |
Weight, g | 492 |
Dimensions W x D x H, mm | 160 x 110 x 26 |
Operating temperature range (T-T), °C | - 20 - 40 |
Power over Ethernet (PoE), W | 70 |
SFP+ slots quantity | 1 |
LED indicators | Power, Per-port Link/ACT, PoE MAX (PoE model only), Per-port PoE (PoE model only) |
Switch type | Unmanaged |
Power over Ethernet (PoE) Support | Yes |
Jumbo Frames support | Yes |
MAC address filtering | Yes |
Auto MDI/MDI-X | Yes |
Data transfer rate, Mbit/s | 33.5 |
Heat dissipation, BTU/h | 56.27 |
SFP slots quantity | 1 |
