network | |
Maximum data transfer rate | 100 Mbit/s |
Converter Eingangsschnittstelle | 10Base-T, 100Base-TX |
Converter output Oberfläche | 100Base-LX |
mesh standard | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x |
Ethernet interfaces type | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
Eigenschaft | Betriebsanleitung |
Services | |
Maximum possible transmission distance | 20000 m |
Kabel mode struktur | Einzelmodus |
Unterstützte Faserkabeldurchmesser (Kern/Mantel) | 3/125,8.7/125,9/125,10/125 µm |
features | |
Product color | Grau |
connections and interfaces | |
transmission technology | Kabelgebunden |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of fiber connectors | 1 |
Optical cable connector | SC |
energy | |
input voltage | 5 V |
input current | 1 A |
Power consumption (standard operation) | 1,5 W |
weight and dimensions | |
broad | 70,3 mm |
depth | 94 mm |
height | 26,2 mm |
operating conditions | |
operating temperatur | 0 - 50 °C |
Operating relative humidity | 5 - 90% |
scope of delivery | |
package weight | 460 g |
certificates | |
certification | FCC Part 15 Class A, CE |
logistic data | |
Country of origin | Taiwan |
