| WAN connection | |
| Eigenschaft | Schnellinstallationsanleitung |
| Wireless LAN functions | |
| WiFi band | Einzelband (2,4GHz) |
| Top WLAN-Standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max.) | 300 Mbit/s |
| network | |
| Interface type Ethernet LAN | Schnelles Ethernet |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| Maximale Sendeleistung (2,4 GHz) | 74,5 dBmW |
| mobile network | |
| Cellular Network Generation | 4G |
| 4G-Standards | LTE-TDD & LTE-FDD |
| supported 4G bandwidths | 700,800,850,900,1800,2100,2300,2600 MHz |
| supported 3G bandwidths | 850,900,2100 MHz |
| SIM card type | NanoSIM |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 4 |
| management functions | |
| safety | |
| Supported security algorithms | WPA-PSK, WPA2-PSK |
| logs | |
| Design | |
| Product color | Schwarz |
| product type | Tabletop-Router |
| scope of delivery | |
| Supplied cables | LAN (RJ-45) |
| Antenna | |
| The Antenna Design | Extern |
| number of antennas | 4 |
| energy | |
| energy source | Gleichstrom |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 60 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| weight and dimensions | |
| broad | 219 mm |
| depth | 140 mm |
| height | 32 mm |
