connections and interfaces | |
transmission technology | Kabellos |
host interface | PCI Express |
interface | WLAN / Bluetooth |
network | |
Maximum data transfer rate | 1800 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Eigenschaft | Schnellinstallationsanleitung |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Data transfer speed WiFi | 11,54,300,574,867,1200 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, CCK, DBPSK, DQPSK, OFDM |
Supported security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
Bluetooth-Version | 5.2 |
Design | |
component for | PC / Server |
Product color | Schwarz |
The Antenna Design | Extern |
Transmission power (CE) | 23 dbm |
Transmission power (FCC) | 27 dbm |
Betriebsmodi | Infrastrukturmodus |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
sustainability | |
weight and dimensions | |
broad | 120,8 mm |
depth | 78,5 mm |
height | 20,9 mm |
package weight | 220 g |
scope of delivery | |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
