| connections and interfaces | |
| transmission technology | Kabellos |
| host interface | PCI Express |
| interface | WLAN / Bluetooth |
| network | |
| Maximum data transfer rate | 1800 Mbit/s |
| mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Eigenschaft | Schnellinstallationsanleitung |
| WiFi band | Dual-Band (2,4 GHz/5 GHz) |
| Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
| WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Data transfer speed WiFi | 11,54,300,574,867,1200 Mbit/s |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, CCK, DBPSK, DQPSK, OFDM |
| Supported security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
| Bluetooth-Version | 5.2 |
| Design | |
| component for | PC / Server |
| Product color | Schwarz |
| The Antenna Design | Extern |
| Transmission power (CE) | 23 dbm |
| Transmission power (FCC) | 27 dbm |
| Betriebsmodi | Infrastrukturmodus |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| sustainability | |
| weight and dimensions | |
| broad | 120,8 mm |
| depth | 78,5 mm |
| height | 20,9 mm |
| package weight | 220 g |
| scope of delivery | |
| Technical details | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
