connections and interfaces | |
transmission technology | Kabelgebunden |
host interface | PCI Express |
interface | WLAN / Bluetooth |
network | |
Maximum data transfer rate | 2402 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Eigenschaft | Schnellinstallationsanleitung |
WiFi band | Tri-Band (2,4 GHz/5 GHz/6 GHz) |
Top WLAN-Standard | Wi-Fi 6E (802.11ax) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
Data transfer speed WiFi | 54,300,1732,2402 Mbit/s |
Supported security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
Bluetooth-Version | 5.3 |
Design | |
component for | PC |
Product color | Schwarz |
The Antenna Design | Extern |
antenna type | 2x2 |
Transmission power (CE) | 5 GHz: 15, 2.4 GHz: 16 |
Transmission power (FCC) | 5 GHz: 20, 2.4 GHz: 20, 6 GHz: 12 |
Betriebsmodi | Infrastrukturmodus |
system requirement | |
Supports Windows operating systems | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 x64, Windows 11, Windows 11 Enterprise x64, Windows 11 x64 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
sustainability | |
weight and dimensions | |
broad | 78,5 mm |
depth | 21 mm |
height | 120 mm |
package weight | 240 g |
scope of delivery | |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
