data transmission | |
Firewall (UDP 1518) Durchsatz | 4,96 Gbit/s |
Firewall (IMIX) Durchsatz | 2,4 Gbit/s |
HTTP-Proxy-Durchsatz | 0,576 Gbit/s |
VPN (IMIX) Durchsatzleistung | 680 Mbit/s |
VPN (UDP 1518) Durchsatz | 2,04 Gbit/s |
Gateway Antiviren-Durchsatzrate | 1,53 Gbit/s |
Aktuelle Verbindungen (Proxy) | 290000 |
WSM-Lizenzanzahl | 0 Lizenz(en) |
Branch-Office-VPN | 60 |
Mobile VPN IPSec | 60 |
Services | |
Simultaneous Connections | 3850000 |
Eigenschaft | Zustandsorientierte Paketüberprüfung (SPI) |
Mean Time Between Failures (MTBF) | 1155348 h |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.3ad |
number of users | 50 Benutzer |
Number of VLANs | 75 |
safety | |
Supported security algorithms | FIPS 140-2, HTTPS, IPSec, SNMPv2, SNMPv3, TLS |
logs | |
Router protocol | BGP, OSPF, RIP |
connections and interfaces | |
transmission technology | Kabelgebunden |
Anzahl der Gigabit-Anschlüsse (Glasfaser) | 8 |
Number of USB 2.0 ports | 2 |
Number of serial ports | 1 |
energy | |
DC input voltage | 90 - 264 V |
Power consumption (standard operation) | 96 W |
certificates | |
Konformitätsbescheinigungen | REACH, RoHS, WEEE |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 85% |
humidity during storage | 10 - 85% |
operating height | 0 - 3000 m |
storage height | 0 - 4570 m |
weight and dimensions | |
broad | 205,5 mm |
depth | 290 mm |
height | 43 mm |
Weight | 2,6 kg |
package weight | 3,1 kg |
scope of delivery | |
Included software | ###REMOVE### |
